Improving Radial Velocities by Marginalizing over Stars and Sky: Achieving 30 m/s RV Precision for APOGEE in the Plate Era

The Big Picture

Imagine trying to hear a whispered conversation from across a stadium while a rock concert is playing. Now imagine that whisper contains the only clue to whether a distant planet exists, or whether two stars are locked in an invisible gravitational embrace. That’s the challenge astronomers face when measuring the radial velocities of stars: detecting tiny shifts in the color of starlight, called Doppler shifts, that betray motion, all while contending with a symphony of interference from Earth’s own atmosphere.

Radial velocity, the speed at which a star moves toward or away from us, is one of astronomy’s most powerful tools. It reveals exoplanets tugging on their host stars, uncovers binary star systems, traces the ghostly streams of disrupted galaxies, and tells us how the Milky Way assembled itself over cosmic time.

Specialized instruments that study one star at a time, like HARPS and ESPRESSO, can detect motions smaller than 1 meter per second. Surveys that observe hundreds of thousands of stars simultaneously sacrifice precision for volume. Until now.

A team of astronomers led by Andrew Saydjari at Harvard has rethought how to extract radial velocities from APOGEE, a decade-long survey that has mapped the motions of millions of Milky Way stars. They squeezed 30 meters per second precision out of an instrument observing 600 stars at once, a result that changes what’s possible in large-scale stellar astronomy.

Key Insight: By simultaneously modeling stellar and sky light rather than subtracting them separately, and by considering all possible stellar types at once rather than committing to a single best guess, the researchers achieved noise-limited radial velocity precision of 30 m/s without upgrading a single piece of hardware.

How It Works

The Apache Point Observatory Galactic Evolution Experiment, APOGEE, spent a decade pointing its twin spectrographs at the Milky Way. Each spectrograph feeds on 300 optical fibers, capturing near-infrared starlight across 15,000–17,000 Angstroms at a spectral resolution of R ~ 22,500, a measure of how finely it can distinguish neighboring wavelengths. The result: 2.6 million individual stellar visits logged in data release DR17. But previous analysis pipelines left precision on the table.

The old approach had two weaknesses. First, sky subtraction (removing the atmospheric glow) happened as a separate, upfront step. Any error in that estimate contaminated every subsequent measurement. Telluric absorption features, where atmospheric gases absorb specific wavelengths, and sky emission lines, bright wavelengths where the atmosphere itself glows, would bleed into the stellar signal and bias velocity measurements.

Second, the pipeline searched for the best-matching stellar template by scanning a grid of options and picking the winner. Grid searches discard information. They throw away all the “almost right” templates and commit to a single answer.

Saydjari and colleagues replaced both steps with a unified probabilistic framework, implemented in a Julia package called apMADGICS.jl. Two innovations make it work:

• Simultaneous component separation: The model fits stellar light, sky emission, and telluric absorption all at once. Each component is modeled jointly, so uncertainty in one propagates correctly into the others. No sequential subtraction, no compounding errors.
• Marginalization over stellar types: Rather than picking one best template, the method integrates over the entire library of stellar types. The stellar type becomes an unknown whose uncertainty folds automatically into the final velocity measurement. Mathematically, it’s equivalent to asking: “Given all possible stellar types, what radial velocity best fits the data?”

The payoff is a much cleaner measurement. Residual sky contamination no longer systematically biases the answer. And the uncertainty estimates are properly calibrated: when the pipeline reports uncertainty X, it actually means it.

Why It Matters

The numbers tell the story. The previous APOGEE pipeline struggled to reach its theoretical limits. On the same fiber, the new catalog achieves noise-limited precision down to 30 m/s, matching the theoretical floor. That’s several times better than what surveys of comparable scale have managed. The closest competitor, the GALAH survey (R ~ 28,000), delivered ~140 m/s precision across ~340,000 stars. APOGEE DR17 covers ~730,000 stars, advancing on both precision and sample size at once.

The team also uncovered something subtle: individual fibers in a multi-object spectrograph (an instrument that captures light from hundreds of stars through separate optical threads) introduce constant velocity offsets relative to each other. This fiber-to-fiber bias had been lurking in APOGEE data, quietly degrading the combined catalog. The new method characterizes and removes these offsets.

After calibration, the combined catalog achieves 47 m/s precision. The gap between 30 and 47 m/s points to the next frontier: improving the line spread function (LSF) models, the precise characterization of how each fiber blurs and distorts incoming light. The authors flag this as a priority for SDSS-V, the ongoing successor survey, where the same APOGEE spectrographs continue operating.

The methodological lesson applies well beyond APOGEE. Any spectroscopic survey contaminated by sky emission or telluric absorption (which is essentially all of them) could benefit from treating the problem as joint inference rather than sequential subtraction. As SDSS-V, 4MOST, WEAVE, and other next-generation surveys come online, this approach could set the standard.

Bottom Line: By replacing sequential pipeline steps with a unified probabilistic model, this work extracts 30 m/s radial velocity precision from APOGEE’s 2.6 million stellar visits, all through software improvements alone.
